Description

Coxreels DM Series Hand Crank Dolly Hose Reel 3/8 in. x 200 ft. - No Hose 4000 PSI Model 117-3-200-DM

COXREELS® DM Series “Dolly Mount” hand crank hose reels offer ultimate lightweight, wheeled portability for long lengths of hose. Eliminate the task of manually coiling and uncoiling hose and easily roll it directly to the work environment. High pressure applications are no problem with a 4,000 PSI rating.

The Coxreels 117-3-200-DM Hand Crank Dolly Hose Reel delivers supreme mobile flexibility via its premium wheeled frame configuration, storing up to 200 feet of 3/8" I.D. line (supplied less hose). Built upon a high-quality three-piece 1-1/4" steel tube frame structure, it rides on solid 8" rubber tires to dominate rugged outdoor terrains. It comes equipped with rubber front feet to prevent forward slipping during active payout, a direct manual hand crank loop, and a removable handle for tight vehicle storage.

Features & Benefits

Wheeled 1-1/4" Steel Dolly Structure: Built with an ultra-robust three-piece 1-1/4" steel tube frame rolling on solid 8" flat-free rubber tires, providing exceptional all-terrain portability and heavy field service lifecycle longevity.
Removable Handle & Anti-Slip Feet: Features a fully removable mechanical handle to provide highly compact storage in truck utility boxes, paired with solid rubber front feet to anchor the dolly against slipping during rapid hose pull out.
Machined Solid Brass 90° Swivel: Outfitted with an external fluid path utilizing a machined solid brass 90° full-flow NPT swivel inlet for low line restriction, swift hose installation, and simple inline seal maintenance without unmounting the reel.
Adjustable Tension Drag Brake: Outfitted with a customizable manual friction drag brake that adjusts the speed of the draw to your exact preference, completely preventing accidental unspooling or free-wheeling during transport or storage.
CNC Robotically Spun Discs: Heavy-duty, robotically spun and ribbed discs feature rolled edges to enhance structural strength, improve overall durability, and protect stored lines from fraying.
American Made Quality: Proudly made in the U.S.A., backed by a leading 2-year manufacturer's limited warranty, and fully sold and supported worldwide.
