Boyd Welding 35 Gallon Fuel Transfer Tank System Aluminum With 15 GPM Pump - 13004-B

Availability: Built To Order - 3-4 Week Lead Time

Save 20% Save 20%
Original price $1,259.95
Original price $1,259.95 - Original price $1,259.95
Original price $1,259.95
Current price $1,007.70
$1,007.70 - $1,007.70
Current price $1,007.70

Boyd Welding 35 Gallon Fuel Transfer Tank System Aluminum With 15 GPM Pump - 13004-B

The Boyd Welding 35 Gallon Fuel Transfer Tank is one of the highest quality aluminum fuel transfer tank systems in the industry. This fuel transfer tank is a customer favorite due to the precise welds, clean smooth aluminum finish, and the unique inset pump pocket design. Built from a heavy duty .125 aluminum, the Boyd Welding 35 Gallon Tank is one of the most durable aluminum tanks on the market. The low profile design of this tank allows it to fit below the bed rail and under a bed cover on most trucks. This transfer tank system comes with a 15 gallon per minute GPI pump, a mechanical fuel gauge, and a rollover vent. See details below to see what makes the Boyd Welding 35 Gallon Transfer Tank one of the highest quality transfer tank options in the industry.

        Damage Free

        Less Than 1% Shipping Damage Rate on Boyd Welding Products

        Made In The USA

        Boyd Welding Tanks Are Proudly Made In The USA In Ocala, FL

        Chat With Us

        The Most Knowledgeable Fuel Tank Reps

        The Best Prices

        Our Out-The-Door Pricing Can't be beat.

        Boyd Welding 35 Gallon Fuel Transfer Tank System

        American Made Quality

        American Made Quality

        Boyd Welding is known as North America’s premier aluminum fuel tank manufacturer. Located in Ocala, FL, Boyd Welding focuses on safety, accuracy, quality welding, excellent appearance and short production times. Each Boyd Welding fuel tank is built from prime scratch free aluminum sheets, T.I.G welded by hand and handled with care through every process ensuring a scratch free finish. Each tank is hydro pressure tested to ensure a leak free tank and is backed by a 2-year structural warranty.

        High Grade Construction

        High Grade Construction

        Boyd Welding utilizes the highest quality materials available with every tank. This 35 Gallon Transfer Tank is built from a thick, high grade, .125 smooth aluminum. Heavy duty mounting tabs are welded to the front and sides of the tank giving you four solid locations to securely mount the tank. Boyd Welding’s attention to quality and detail guarantees perfect welds and a clean, scratch free finish.

        Unique Inset Pump Pocket Design

        Unique Inset Pump Pocket Design

        Boyd Welding transfer tanks feature a unique inset pump pocket design. This design keeps the pump low and keeps the overall height of the transfer tank system short enough to allow this tank to sit below the bed rail on most trucks. A lot of our customers love this design because it allows the transfer tank system to fit under most bed covers. This tank comes standard with the inset pump pocket on the passenger side of the tank.

        35 Gallon Transfer Tank Dimensions

        35 Gallon Transfer Tank Dimensions

        The Boyd Welding 35 Gallon Transfer Tank is 48” wide, 12” deep, and 18” tall. Including the mounting tabs on the sides of the tank, the overall width is 51”. Including the mounting tabs on the front of the tank, the overall depth is 13.5”. Including the fuel fill cap, the overall height of the tank is 19.975”. See dimension drawing in the product images section for accurate dimensions and other specifications.

        GPI 15 GPM Transfer Tank Pump Included

        GPI 15 GPM Transfer Tank Pump Included

        To match the quality of the Boyd Welding tanks, a GPI pump is included with this tank. This GPI M-150S pump features a rotary gear design and is made from a durable and light weight cast aluminum. The aluminum housing is rugged and corrosion-resistant to withstand years of work in any application. The 12-volt DC motor generates 1/5 horsepower to deliver flow rates up to 15 GPM. The M-150S is the bestselling fuel transfer pump in retail, providing longer run times and award-winning performance year over year. This pump comes with a manual unleaded nozzle, 10ft fuel hose, 18ft power cord, and an adjustable suction pipe.

        Items Included With This Tank

        Items Included With This Tank

        - GPI 12v 15GPM pump, fuel hose, manual nozzle, and power cord

        - ½” NPT Rollover Vent

        - Mechanical Fuel Gauge

        - Boyd Welding 2" Non Vented Cap

        Items NOT Included With This Tank

        Items NOT Included With This Tank

        - Mounting Hardware

        - Permanent drain plugs or valves depending on your installation, BLUE PLUGS ARE FOR SHIPPING ONLY AND MUST BE REMOVED BEFORE ANY LIQUID IS PUT IN THE TANK.

        - Vent hose and small filter for rollover vent

        - Electrical connectors to wire the supplied cord to your battery source.

        - Brass Fittings are ok to use and are recommended for drain plugs or valves.

        Knowledgeable Customer Support

        Knowledgeable Customer Support

        Our US-Based Customer Support Team is very knowledgeable of the Boyd Welding product line. Customer Service is a core value of Elite Truck, and a part of that is being able to answer any question or know where to get an answer.

        Elite Truck Sales & Support Team attends the commercial vehicle trade shows and vendor training seminars. Trust that when you're buying from Elite Truck you're not only getting great prices, but industry leading customer support.

        If you want to know more about the Boyd Welding products, our North & South Carolina-based support teams can help you.
